ITM-LAB builds industrial-grade drop testing machines designed to eliminate the variables that ruin testing data.
Our lineup includes everything from high-capacity single-arm and dual-wing packaging testers to automated, 6-axis robotic drop systems built specifically for magnetic wireless charging smartphones. Engineered to exceed strict ASTM D5276 and ISTA accuracy standards, our hardware guarantees a true, zero-drag free fall with a ±1° orientation precision—giving electronics manufacturers and QA labs across Europe, the Middle East, and Southeast Asia data they can actually rely on.
The Automatic Drop Test Machine RS-DP-03A2 is designed to evaluate the impact on product performance when a customer accidentally drops the product during actual use. It is suitable for directional drop tests on portable consumer electronic products such as mobile phones, tablets, chargers, e-books, electronic dictionaries, batteries, touch screens, headphones, etc.
The Spindle Torque Endurance Testing Machine rs-6700(servo type) is designed for LCD MONITOR liquid crystal display, V liquid crystal TV, all-in-one computer, etc. After many times of forward tilt and backward swing test, whether the rotor shaft still has the holding force or the rotor shaft resistance becomes large and damages the plastic body.
The RS-315 Single Arm Package Drop Tester simulates real transportation drop conditions to test the impact resistance and durability of packaged products. It performs face, edge and corner free-fall tests to verify packaging protection performance, widely used in packaging factories, QC labs and certification institutions.
-
Wide Application: Tests product packaging for damage due to drops during transportation and handling.
-
Stable Design: Single-arm double-column structure ensures smooth lifting and prevents lateral shaking during operation.
-
Electric Arm Reset: Automatic reset function for the arm, ensuring operator safety and efficient operation.
-
Hydraulic Cushioning: Absorbs impact energy to reduce damage to the equipment and extend its service life.
-
Precise Control: Digital height display and adjustable drop height for accurate and automatic stop at set height.
-
Versatile Sample Fixture: Quickly positions packaging of different sizes for efficient testing.
- Dual-column Guide Design: Provides stable and reliable guidance for large and heavy packaging tests.
- Hydraulic Lift System: Ensures smooth and powerful height adjustments for precise drop testing.
- Zero Drop Height Capability: Adjustable from 0 to 1200 mm (varies by model) for accurate testing of packaging resilience.
- Comprehensive Drop Testing: Supports corner, edge, and flat surface drop tests to simulate real-world conditions.
- Reliable Drop Mechanism: Uses SMC pneumatic cylinders to ensure consistent drop acceleration and safe, noise-reduced landings.
- Safety Features: Equipped with a backup battery system for power failure protection and smooth descent.
- Conforms to Industry Standards: Meets ISTA 1A, ASTM D5276, GB/T4857.5-92, and GB/T1019-2008 for drop testing protocols.
- Wide Drop Height Range:
-
- RS-315: 300mm to 1500mm
- RS-320: 300mm to 2000mm
- High Load Capacity: Supports up to 100kg, suitable for various product sizes and weights.
- Accurate Testing: Drop angle error ≤5°, height display accuracy ≤2% of set value.
- Spacious Test Area: 800×600×1000mm, accommodating a wide range of items.
- Durable & Reliable: Sturdy construction with long-term operational stability.
- Versatile Applications: Ideal for toys, electronics, furniture, packaging, and more.
The Safety Glass Drop Ball Impact Tester RS-8220LQ is designed according to GB/T9962-1999 Safety Glass Materials for Building Use - Safety Glass Performance Specification and Test Methods, 6.10 Falling Ball Impact Peeling Performance Methods, to meet the requirements of impact testing of safety laminated glass for building use.
Test standard
JIS R3205∶ 1989、ISO/DIS12542112543-6:1997 AS/NZS2208:1996、GB/T9962-1999
The RS-DP-04-2D Micro-Drop Tester is designed for testing small electronic consumer products, such as mobile phones, tablets, e-readers, chargers, and more. This device simulates the minor drops that occur during everyday use, such as dropping the product onto a tabletop or similar surface, to evaluate the durability of the outer shell and the impact resistance of the internal structure.
The Controlled Drop Test Machine is designed for cell phone, walkie-talkie, electronic dictionary, building and apartment intercom telephone, CD/MD/MP3 and other small consumer electronic products and parts for free fall test, in order to assess the product at a certain height by diamond, corner, surface drop test, function and structure is reliable.
